JF-99770 Gray
JF-99770 Gray 3-Speed AC Ceiling Fan Remote and Receiver Kit
JF-99770 Gray is a gray version listed in the JF-99770 AC fan control range. The matched RF remote and receiver provide three fan speeds, light on/off and brightness adjustment. Published functions and electrical ratings match the JF-99770 listing; confirm the precise finish and supplied components when ordering.
Motor
AC
Interface
RF remote
Input rating
110–120 V AC, 50/60 Hz
Parameter
Specification
Motor type
AC
Input voltage
110–120 V AC, 50/60 Hz
Motor / light load
Motor: 1 A max; light: 180 W max
Remote Control Range
30 ft
Fan & light functions
3 fan speeds; light on/off; brightness adjustment
RF frequency
433 MHz
Housing dimensions
115 × 50 × 28 mm (L × W × H)
Final specifications follow the approved model datasheet.
Compare this product family · Selection guide · OEM / ODM review
Receiver dimensions in millimeters. Allow additional space for cables and connectors.
FIT & CONNECTION
Dimensions
& Interfaces.
Check the fit before confirming the model.
Installation space
The receiver is listed at 115 × 50 × 28 mm. Allow extra room for connectors and wiring. Compare the chosen gray model with the approved product image and receiver drawing before confirming the canopy fit.
Electrical connection
The listed input is 110–120 V AC, 50/60 Hz, with a 1 A motor limit and 180 W light limit. Confirm the lamp or driver type, light-dimming method and 433 MHz coding. The gray finish does not establish a different load rating or compatibility range.
